Second-hand Machines
Baudrand New Tech presents the list of second-hand machines available as of today.
The majority can be inspected in Lyon; for those in Barcelona, the place of standing is indicated in the “Informations” column.
1. Compression Spring Coilers
| Model | Max. wire diameter (mm) | Informations |
|---|---|---|
| Bobbio BTS 300 | 3 | Segment type, max feeding lenght 1,6 m |
| Bobbio BX 400 | 4 | Clutch type, max feeding lenght 28 m |
| Hack SM 60 | 6 | Segment type, max feeding lenght 3 m |
| Hack UFA 16 | 16 | Clutch type, max feeding lenght 34 m |
| Herckelbout 10 B | 3 | Segment type, max feeding lenght 3 m |
| Herckelbout 8 M & PR 8 & PR 8 T | 0.8 | Segment type, max feeding lenght 1,5 m |
| Schenker FA 15 S Ecaset | 1.5 | Segment type, max feeding lenght 1,2 m (2 machines available) |
| Schenker FA 20 S | 2 | Segment type, max feeding lenght 1,5 m |
| Schenker FA 30 S Ecaset | 3.5 | Segment type, max feeding lenght 1,6 m |
| Schenker FA 60 S Ecaset | 6 | Segment type, max feeding lenght 1,85 m |
| Schenker FA 6 S | 0.8 | Segment type, max feeding lenght 0,85 m (several mcs, some with gage) |
| Schenker FA 6 S (1) | 0.8 | For spare parts |
| Simplex Rapid A/O-20 + Schenker M10 | 2 | Decoiler included |
| Simplex Rapid A2S-93 | 5 | Clutch type, max feeding lenght 67 m (2 machines available) |
| Wafios FM 50 | 5 | Incomplete tools, LH coiling plate unavailable Segment type, max feeding lenght 2,4 m |
| Wafios FM 8 (1) | 0.8 | Segment type, max feeding lenght 0,94 m |
| Wafios FM 8 (2) | 0.8 | Segment type, max feeding lenght 0,94 m Specific modifications – Decoiler included |
| Wafios FS 2 + FRM 43 gage | 0.8 | Segment type, max feeding lenght 0,9 m |
| Wafios FS 2 | 0.8 | Segment type, max feeding lenght 0,9 m |
2. Compression Spring Coilers – CNC
| Model | Max. wire diameter (mm) | Informations |
|---|---|---|
| Bamatec 8 BCX | 0,8 | 5 axes, Microstudio camera |
| Bamatec 8 SC | 0.8 | 2 axes, Moyer MR 44 gage |
| Herckelbout TC 60 | 8 | 2 axis CNC |
| Schenker FA 15 S Retrofit by Bamatec | 1.5 | 2 axes |
| Schenker FA 20 S Retrofit by Bamatec | 2 | 2 axes, Moyer MR 44 gage |
| Wafios FUL 10 | 16 | Bosch-Rexroth CNC & mechanical retrofit in process |
3. Extension Spring Coilers – Mechanical & CNC
| Model | Max. wire diameter (mm) | Informations |
|---|---|---|
| Herckelbout-Pernin PR 101 | 1 | Segment type, max feeding lenght 1,5 m |
| Shinko VF 812-MFT | 1.2 | 3 axis – impressive amount of tools
500kg motorized decoiler included |
| Simplex Rapid K117 A 1 SDO | 1.8 | 2 machines available Decoilers included |
| Wafios ZO 1 | 0.5 | 2 machines available Decoilers included |
4. Torsion Spring Coilers
| Model | Max. wire diameter (mm) | Informations |
|---|---|---|
| Hack ASF 2B | 2.5 | Hydraulic slides |
| Hack ASP 1P | 1 | Pneumatic slides |
| Wafios FTU 2 | 2 | |
| Wafios FTU 3 | 3.5 |
5. Torsion Spring Coilers – CNC
| Model | Max. wire diameter (mm) | Informations |
|---|---|---|
| Nucoil CSF 400 | 3.6 | 4 axis |
| TC.HP T15 CN | 1.5 | CNC out of order |
6. Wire and strip benders – Mechanical
| Model | Max. wire diameter / strip (mm) | Informations |
|---|---|---|
| Bihler RM 25 | 2 – 30 | 4-tons press |
| Bihler RM 30 | 2.5 – 40 | 5 tons press |
| Bihler RM 35 | 2.5 – 32 | 7 tons presses (5 machines available) |
| Bihler RM 40 | 3 – 60 | 9 tons presses |
| Bihler GRM 50 | 5 – 40/70 | 25-tons presses |
| Bihler | Slides and presses for RM 35 / GRM 50 | |
| Finzer ZUB 200 | 3 – 50 | 6-tons press |
| Finzer ZUB 200 | 3 | No press – ZUB 100 HS feeding system |
| Herckelbout MS 10 | 1 | No press |
| TC.HP MS 30 | 3 | No presses – CNC feeding (2 available) |
7. Others
| Model | Max. wire diameter (mm) | Informations |
|---|---|---|
| CNC wire bending machines | ||
| Wafios BM 3 (CNC) | 6 | Wafios AHL 41 decoiler (1,500 kg payload) included |
| Copper enamelling devices | ||
| Wafios FSA 1 (3 devices) | 1.5 | |
| Wafios FSA 2 | 2.5 | |
| Decoilers | ||
| Decoilers | Various motorized models Capacity from 30 to 1.500 kg |
|
| Feeders – CNC | ||
| Latour CNC feeder | 10 | To mount onto any machine |
| Grinders | ||
| Hack FSA 1 | 1 | Loading plate 225 mm, grinding discs 175 mm |
| Herckelbout MV 2 | 2 | Loading plate 450 mm, grinding 350-450 mm (3 machines available) |
| Herckelbout MV 3 | 3 | Loading plate and grinding discs 600 mm |
| Schenker FS 12 | 14 | Loading plate 600 mm, grinding discs 800 mm |
| Wafios FEL 3 | 10 | Loading plates and grinding discs : 600 mm (2 machines available) |
| Ovens | ||
| Vertical oven for stress relieving | Int. dia 600 mm | 2 available |
| CMT | Horizontal oven for tempering & stress rel. | |
| SLMT-SLFI | Horizontal oven for tempering & stress rel. | |
| Profile projectors | ||
| Orama 500 | ||
| Rotating wire straighteners | ||
| Finzer Rotating wire straightener | 0.8 | 4 equipment available |
| Vitari NR 210 | 4 | New equipment – never used |
| Soundproof cabin | ||
| Soundproof cabin | Originally used for a Bihler RM 35 |
|
| Surface Grinders | ||
| Haas semi-automatic | ||
| PLH 300H | ||
| Manual Surface Grinder | ||
| Oil dryer | ||
| Polyservice Petitjean ECO 600 | Rotating barrel to get rid of oil on components | |
| Load testers | ||
| Boehm Elektronik | 50 kg | Compression & extension |
| Boehm Elektronik | Up to about 2,0 mm | Torsion – to be repaired |
